25.6V 50Ah Prismatic LiFePO4 Battery Pack
Ideal for Energy Storage Systems, Backup Power, or Light Electric Vehicles
- Product number: 00BQ2450-01
- Nominal voltage: 25.6V
- Nominal capacity: 50000mAh
- Battery size: 170*240*350mm
- Charging temperature: 0～55℃
- Discharging temperature: -20～55℃
- Application areas: Robot, UPS, energy storage
- Project No.: 00BQ2450-01
- Cell model: LF50/50.0Ah/3.2V
- Battery specification: LF50-8S1P/52.0Ah/25.6V
- Nominal voltage: 25.6V
- Nominal capacity: 50.0Ah
- Charging voltage: 29.2V
- Charging current: ≤25.0A
- Discharge current: 50.0A
- Instantaneous discharge current: 60A
- Discharge cut-off voltage: 20.0V
- Finished product internal resistance: ≤100mΩ
- Battery weight: ≤12.0kg
- Product size: 170*240*350mm
- Charging temperature: 0～55℃
- Discharge temperature: -20～55℃
- Storage temperature: -20～45℃
- Battery shell: sheet metal shell
- Intelligent lithium battery protection: power management (RS485, CAN protocol), short circuit protection, overcharge protection, over discharge protection, over current protection, over temperature protection, etc.
- Application areas: robots, UPS, energy storage
