32650 24V 100Ah LiFePO4 Battery for Emission Instrument of Special Equipment
Designed for industrial emission instruments, providing long cycle life and stable power output.
-
Model number:03EQ123-01
-
Nominal voltage:24.0V
-
Nominal capacity:96000mAh
-
Battery cell:32650/3.2V/6Ah
-
Dimension:350*320*180mm
-
Application:ocean monitoring, industrial equipment, emergency power supply of portable emission instrument, etc.
- Product number: 03EQ123-01
- Cell model๏ผ32650/3.2V/6Ah
- Battery specification: 32650-8S16P/24V/96Ah
- Nominal voltage๏ผ24V
- Nominal capacity๏ผ96Ah
- Charging voltage: 29.2V
- Charging current: โค20A
- Discharging current: 10A
- Instant discharging current: 50A
- End-off voltage: 18.4V
- Internal resistance: โค150mฮฉ
- Battery weight: 23.0kg
- Product dimension: 350*320*180mm๏ผMax๏ผ
- Charging temperature๏ผ0๏ฝ45โ
- Discharging temperature: -20๏ฝ60 โ
- Storage temperature: -20๏ฝ60 โ
- Temperature protection: 65โยฑ5โ
- Battery case: cold rolling and metal plate
- Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection, etc.
- Application: ocean monitoring, industrial equipment, emergency power supply of portable emission instrument, etc.
1. Fast connect: adopt push-pull self-locking connector, which is efficient, safe and reliable.
2. Data communication management: adopt IC+TI charger management chip, precise data transmission and accurate temperature control so as to try our best to eliminate the security risks.
3. The battery pack has good security, professional handle, nice low temperature performance and long cycle life.
4. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
5. Shock-resistant and waterproof: fill in the shock-resistant structure inside the cold rolling metal plate housing to satisfy the requirements of good security and high reliability.
