41AQ501

This rechargeable smart lithium-ion battery pack is designed specifically for compact handheld devices. The 41AQ501 (2S1P) 7.2V smart Li-ion battery integrates the safety and functionality features trusted by designers and engineers, while delivering exceptional power and reliability.
Large Battery’s rechargeable smart Li-ion packs can operate in low-temperature environments down to -20°C, thanks to their low internal resistance, which ensures stable capacity and discharge performance.

Length X Width X Height (Inches):3.36″ X 1.65″ X .88″
Length X Width X Height (mm):85mm X 42mm X 23mm
Energy (Wh):24 Shape:Rectangular
Chemistry / Cell Array:2 Li-ion 18650 cells / 2S1P array
Equivalent Lithium Content:≤2g
Cavity Size:24mm x 43mm cross-section
Fuel Gauge Display:Always on 5-Bar LCD
IP Rating:None

SMBus Communication
• Convenient pull tab for easy removal
• LCD display on the pack for relative SOC indication

Our expertise lies in developing customized hybrid battery systems that seamlessly integrate standard components to achieve optimal performance.
Want to speak with our experts? Click here to contact us.

41AQ501 Smart Li-ion Battery Customization Options:
• SHA-1 security handshake
• Custom labeling
• Custom firmware
• Additional performance options for OEM applications

Need IEC, UL, CSA 62133-2, KC, or BIS PSE certifications?
Consider our 41AQ502 Smart Battery.

Looking for higher discharge rates and improved low-temperature performance?
We recommend the 41AQ503 Smart Battery.

Need extra capacity?
Check out our 41AQ505 Smart Battery.
