41AQ503
The 41AQ503 battery pack offers a higher discharge rate and lower operating temperature than the standard 41AQ503 smart battery, while maintaining the trusted safety and functionality features valued by designers and engineers — including SMBus communication, a convenient pull tab for easy removal, and an on-pack LCD display for relative SOC indication.
The 41AQ503 (2S1P) 7.2V Li-ion battery pack has been tested to operate reliably at temperatures as low as -30°C, making it ideal for compact handheld devices. (Note: For low-temperature applications, we strongly recommend conducting validation tests within your specific use case.)
The 41AQ503 cell provides an 8A discharge capability, making it an excellent choice as a small hot-swappable battery to power devices temporarily while the main battery is being charged.
Dimensions (L × W × H):
• Inches: 3.36″ × 1.7″ × 0.9″
• Millimeters: 85 mm × 42 mm × 23 mm
Energy (Wh): 20
Shape: Rectangular
Chemistry / Cell Configuration: 2 × 18650 Li-ion cells / 2S1P configuration
Lithium Equivalent Content: ≤ 2 g
Cavity Size: 24 mm × 43 mm cross-section
Fuel Gauge Display: Always-on 5-bar LCD indicator
IP Rating: None
Features:
• SMBus communication
• Convenient pull tab for easy removal
• LCD display on the pack for relative State of Charge (SOC) indication
Our expertise lies in developing custom hybrid battery systems that seamlessly integrate standard components to achieve optimal performance.
Want to consult with our experts? Click here to contact our technical, engineering, and manufacturing team based in Newberry, Florida.
41AQ503 Smart Li-ion Battery Customization Options:
• SHA-1 security handshake
• Custom labeling
• Custom firmware
• Additional performance options for OEM applications
It is recommended to use the N-Series charger for charging these batteries.
