The 41AQ518 is an IEC, UL, and CSA 62133-2 certified model. As a 4S1P smart lithium-ion battery with 14.4V voltage and 4A output, it comes equipped with the standard features that designers and engineers trust for safety and functionality—including SMbus support, a pull tab for easy removal, and an on-pack LCD display showing relative State of Charge (SOC).
The 41AQ518 series of large rechargeable smart Li-Ion battery packs are ideally engineered for handheld devices, offering a range of options to meet diverse design and performance needs:
- ND2034ED34 (4S1P): 14.4V, 8A
- ND3034HD29 (4S1P): 14.4V, 10A (discharge temperature range: -30°C to +60°C)
- ND2037HD34 (2S2P): 7.2V, 8A
- ND2037QE34 (2S2P): 7.2V, 8A (IEC, UL & CSA 62133-2 certified)
- ND3037HD29 (2S2P): 7.2V, 10A (discharge temperature range: -30°C to +60°C)
Length X Width X Height (Inches):
6.0″ X 1.7″ X 0.9″
Length X Width X Height (mm):
153mm X 42mm X 23mm
Chemistry / Cell Array:
4 Li-ion 18650 cells / 4S1P array
Equivalent Lithium Content:
≤4g
Cavity Size:
24mm x 43mm cross-section
Fuel Gauge Display:
Always on 5-Bar LCD
