41AQ541
41AQ541 Smart Li-ion Battery
The 41AQ541 is well-suited for low-temperature applications, as its low internal resistance allows for strong capacity delivery and reliable discharge performance in cold environments.
The pack has been tested to operate reliably at temperatures as low as −30°C.
(Note: For low-temperature applications, performance validation in the actual device environment is strongly recommended.)
In addition, the 10A discharge capability makes the 41AQ541 an ideal small hot-swappable battery, supplying temporary power while the main battery is being charged.
| Item | Specification |
|---|---|
| Dimensions (L × W × H) | 5.9 in × 2.4 in × 0.9 in |
| Dimensions (mm) | 151.1 mm × 59.02 mm × 22.4 mm |
| Energy (Wh) | 60 Wh |
| Shape | Rectangular |
| Chemistry / Cell Configuration | 6 × 18650 Li-ion cells / 3S2P configuration |
| Lithium Equivalent Content | 6 g |
| Cavity Size | Cross-section: 23.5 mm × 60 mm |
| Fuel Gauge | Always-on 5-bar LCD display |
| IP Rating | None |
Features:
• SMBus communication
• Convenient pull tab for easy removal
• On-pack LCD display for relative State of Charge (SOC) indication
Our expertise lies in developing custom hybrid battery systems that seamlessly integrate standard components for optimized performance and reliability.
Contact us anytime for engineering assistance or OEM customization.
41AQ541 Smart Li-ion Battery Customization Options:
• SHA-1 security handshake
• Custom labeling
• Custom firmware
• Additional performance options for OEM applications
