41AQ580
The 41AQ580 is a high power density smart battery, ideal for uninterruptible power supply (UPS) systems and low-current DC motors. It uses high power density Li-ion manganese cells to deliver very high currents for short periods, comes with a new standard connector for higher operating voltage and discharge currents, and has a rugged construction rating that matches its use in mobile environments.
Length X Width X Height (Inches):
6.62″ X 3.22″ X 1.10″
Length X Width X Height (mm):
168.1mm X 81.8mm X 27.7mm
Energy (Wh):
81
Shape:
Rectangular
Chemistry / Cell Array:
8 Li-ion 18650 cells / 8S1P array
Equivalent Lithium Content:
≤4g
Cavity Size:
27.8mm x 98.1mm cross section
Fuel Gauge Display:
Always on 5-Bar LCD
Large-battery specializes in customizable smart Li-ion batteries tailored to unique specifications, offering options such as custom labels, custom firmware, and select performance adjustments. Additionally, it has established expertise in developing custom hybrids from standard batteries.
