Dimensions (inches): 3.74″ × 2.95″ × 1.08″
Dimensions (mm): 94.89 mm × 74.81 mm × 27.26 mm
Energy (Wh): 54
Shape: Square
Chemistry / Cell Configuration: 3 × 21700 Li-ion cells / 3S1P configuration
Lithium Equivalent Content: ≤ 2 g
Cavity Size: 27.8 mm × 76.4 mm cross-section
Fuel Gauge Display: Button-activated 4-bar LED display
41AQ513
The Large Battery 40xx Series of rechargeable smart lithium-ion battery packs utilize 21700 cells, designed for applications that demand a balance between compact size and extended runtime.
The 41AQ513 (3S1P) 10.8V smart Li-ion battery integrates the safety and functionality features trusted by designers and engineers, including SMBus communication, a convenient pull tab for easy removal, and an on-pack LED display for relative State of Charge (SOC) indication.
The 41AQ513 battery pack performs reliably in low-temperature environments down to -20°C, with low internal resistance that enables excellent capacity retention and discharge performance.
(Note: For low-temperature applications, we recommend testing the device at the intended operating temperature to verify performance.)
Designed for compact and handheld devices, this battery is IEC, UL, CSA 62133-2, BIS, KC, and PSE certified, meeting the highest international standards for safety and performance.
Features:
• SMBus communication
• Convenient pull tab for easy removal
• On-pack LCD display for relative State of Charge (SOC) indication
Our expertise lies in developing customized hybrid battery systems that seamlessly integrate standard components to achieve optimal performance.
Want to connect with our experts? Click here to contact us.
41AQ513 Smart Li-ion Battery Customization Options:
• SHA-1 security handshake
• Custom labeling
• Custom firmware
• Additional performance options for OEM applications
