Custom Lithium ion Battery Pack
Product number: 01DQ0030-08
Cell model: 18650-3350MAH-3.6V
Battery specification: 18650-1S1P-3350MAH-3.6V
Product dimension: 69.5*φ19.5mm (Max)
Nominal voltage: 3.6V
Nominal capacity: 3350mAh
Charging voltage: 4.2V
Charging current: ≤2A
Discharge current: ≤4A
Discharge cut-off voltage: 2.5V
Finished product internal resistance: ≤150mΩ
Battery weight: 60G
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60 ℃
Storage temperature: -20 to 35 ° C
Battery package: PVC heat shrinkable film
Output: A1251 connector
Lithium battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection,ESD protection, etc.
Application: temperature tester, handheld terminal test equipment, medical equipment
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
