Product number: 01WQ0011-01
Executive standard:GB31241-2014
Cell model: INR18650-35E/3350mAh/3.6V
Battery specification: 18650-4S2P/6700mAh/14.4V
Nominal voltage:14.4V
Nominal capacity:6700mAh
Charging voltage: 16.8V
Charging current: ≤3.35A
Discharging current: 15.0A
Instant discharging current: 30.0A
End-off voltage: 11.2V
Internal resistance: ≤250mΩ
Battery weight: 550g
Battery package:ABS+PC
Product dimension: 60.3×69.0×214.3mm
Charging temperature:0~45℃
Discharging temperature: -20~60℃
Storage temperature: -20~23℃
Product certificate:CE/CB(IEC62133)/UN38.3 ETC
Battery management: charging management,power management,short circuit/overcharge/over discharge/over current protection, etc.
