26650 12.8V 17Ah LiFePO4 Battery for Power Monitoring Equipment

Customization | Free Battery Solution

Product Detail

Product number: 01DQ0132-02

Cell model: 26650-4000MAH-3.2V

Battery specification: 26650-4S5P-17AH-12.8V

Product dimension: 213*84*103mm (Max)

Nominal voltage: 12.8V

Nominal capacity: 17Ah

Charging voltage: 14.4V

Charging current: ≤3A

Discharge current: ≤3A

Discharge cut-off voltage: 8.0V

Internal resistance of finished product: ≤50mΩ

Battery weight: 2600 GB

Charging temperature: 0 ~ 45℃

Discharge temperature: -20 ~ 60 ℃

Storage temperature: -20 to 35 ° C

Battery package: blue PVC heat shrinkable film

Output: Molex plug

Application: Power testing equipment, testing equipment
