Product number: 01DQ0023-51
Cell model: 18650-3350MAH-3.6V
Specification: 18650-1S1P-3350MAH-3.6V
Product size: 69.5*19.5mm (Max)
Nominal voltage: 3.6V
Nominal capacity: 3350mAh
Finished product internal resistance: ≤150mΩ
Charging voltage: 4.2V
Charging current: ≤1.5A
Discharge current: ≤1.5A
Discharge cut-off voltage: 2.5V
Battery weight: 60G
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60 ℃
Storage temperature: -20 to 35 ° C
Battery package: blue PVC heat shrinkable film package
Lithium battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection,ESD protection, etc.
Application: smoke alarm, fire alarm
Product Features
1.Protective blue PVC heat shrinkable film package is simple, reliable and easy to be installed.
2.Connector plug output terminal: The JST plug is used to increase the reliability of electrical conduction.
3.Battery protection management: Adopt imported seiko protection chip with good stability, high precision monitoring and precise control, to eliminate potential safety hazards to the maximum.
4.The battery pack has good safety, nice discharge performance and long cycle life.
5.The battery has long cycle life, in line with low carbon, energy saving, environmental protection values;
