22.2V 2.2Ah 18650 Lithium Ion Battery BIC Battery for On-board Computer Terminal
-
Suitable for logistics, fleet management, and transportation monitoring systems.
-
Model number:13BQ1887-03
-
Nominal voltage:22.2V
-
Nominal capacity:2200mAh
-
Battery cell:18650/3.7V/2.2Ah
-
Dimension:136*58*30mm（Max）
-
Application:on-board computer terminal, rail traffic testing equipment
- Product number: 13BQ1887-03
- Cell model：18650/3.7V/2.2Ah
- Battery specification: 18650-6S1P/22.2V/2.2Ah
- Nominal voltage：22.2V
- Nominal capacity：2.2Ah
- Charging voltage: 25.2V
- Charging current: ≤2A
- Discharging current: 2A
- Instant discharging current: 3.0A
- End-off voltage: 18.0V
- Internal resistance: ≤580mΩ
- Battery weight: 400g
- Product dimension: 136*58*30mm（Max）
- Charging temperature：0～45℃
- Discharging temperature: -20～60 ℃
- Storage temperature: -20～35 ℃
- Battery case: blue PVC
- Lithium ion battery protection: short circuit protection, overcharging protection, over-discharging protection and overcurrent protection.
- Application field: on-board computer terminal, rail traffic testing equipment
