Product number: 00AQ015-01
Cell model: 18650/3350mah /3.6V
Specifications: 18650/4S6P/19Ah/14.4V
Product size: 250±0.3mm×82.0±0.2mm×71±0.3mm
Nominal voltage: 14.4V
Nominal capacity: 19Ah
Charging voltage: 16.8V
Charging current: ≤ 9.5A
Discharge current: ≤19A
Discharge cut-off voltage: 10V
Product internal resistance: ≤180mΩ
Battery weight: ≤ 1700G
Charging temperature: 0 ~ 45℃
Discharge temperature: -40°C ~+55 °C
Storage temperature: -40 to +45 ° C (less than 1 month) -30 to 35 ° C (less than 3 months); -20~+20℃ (less than 6 months)
Battery package: aluminum alloy case, conductive oxidation surface, natural color
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, etc.
Application: Equipment
Product Features
1.Aluminium alloy shell
2.Output terminal: Adopt the output mode of GB UL wire to increase conductive reliability.
3.Battery protection management: Adopt well-known protection chips with good stability, high precision monitoring and precise control, to minimize safety risks.
4.The battery pack has good safety, nice discharge performance and long cycle life.
5.The battery cycle life is long, in line with low carbon, energy saving, environmental protection values;
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
