Cell model: 18650 3.6V/3300mAh
Nominal voltage: 10.8V
Nominal capacity: 13200mAh
Charging voltage: 12.6V
Charging current: ≤5A
Discharge current: 5A
Instantaneous discharge current: 7-9A
Discharge cut-off voltage: 8.1V
Finished product internal resistance: ≤150mΩ
Battery weight: 600G
Product size: 19*70*227.9mm
Charging temperature: 0 ~ 45℃
Discharge temperature: -40 ~ 60 ℃
Storage temperature: -40 to 60 ° C
Battery package: PVC package
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, SMBUS communication, etc.
Application: Portable testing equipment
1.Energy consumption is low;
2.Smart coulometer, SMBUS communication
3.The battery pack is safe and has long cycle life.
4.The battery cycle life is high, in line with low carbon, energy saving, environmental protection values;
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
