Product number: 37DZ088-01
Cell type: 26650/3.2V/ 3.6AH
Nominal voltage: 48V
Nominal capacity: 10.8Ah
Charging voltage: 54.75V
Charging current: ≤5.0A
Discharge current: 10A
Instantaneous discharge current: 30A
Discharge cut-off voltage: 37.5V
Product internal resistance: ≤200mΩ
Battery weight: 7.5Kg
Product size: 190*120*240mm
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60 ℃
Storage temperature: -20 to 45 ° C
Temperature protection: 65℃±5℃
Battery cover: Sheet metal cover
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, temperature protection, balance and so on
Application: medical devices
1.Large current output;
2.Built-in temperature protection for the battery,
3.The battery comes with a charge detection port.
4.485 Communication Management: SOC management, fault warning, etc.
5.The battery pack is safe and has long cycle life.
6.Charge at a cost of 0.5C.
7.The battery pack has a long cycle life and conforms to the values of low-carbon, energy saving and environmental protection.
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
