Project number: 16AQ369-21
Cell model: LR18650LD/2500mAh/3.6V
Specification: 18650/7S2P/4.6Ah/25.2V
Nominal voltage: 25.2V
Nominal capacity: 4.6Ah
Charging voltage: 29.4V
Charging current: ≤2.15A
Discharge current: 15.0A
Instantaneous discharge current: 21.0A
Discharge cut-off voltage: 19.25V
Finished product internal resistance: ≤150mΩ
Battery weight: 750G
Product size: 59*70*165mm
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 to 25 ° C
Battery case: PVC+ plug cable output
Intelligent lithium battery protection: power calculation, short circuit protection, over charge protection, over discharge protection, over current protection, etc.
Application: Medical care bed
