Project number: 01DQ0142-01
Cell model: 628053/3900mah /3.8V
Specification: 628053/4 s2p / 7800 mah / 15.2 V
Nominal voltage: 15.2V
Nominal capacity: 7800mAh
Charging voltage: 17.4V
Charging current: ≤3.9A
Discharge current: 5.0A
Instantaneous discharge current: 8.0A
Discharge cut-off voltage: 12.0V
Product internal resistance: ≤200mΩ
Battery weight: 450G
Product size: 13*60*325mm
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 to 35 ° C
Battery case: /
Intelligent lithium battery protection: power management, short circuit protection, over charge protection, over discharge protection, over current protection, etc.
Application: Rugged laptop
