26650 48V 14Ah LiFePO4 Battery for Fire-fighting Robot with RS485 Communication Port
-
Suitable for autonomous emergency response systems requiring long cycle life and industrial-grade safety.
-
Model number:04EQ029-01
-
Nominal voltage:48.0V
-
Nominal capacity:14000mAh
-
Battery cell:26650/3.2V/3.5Ah
-
Dimension:290×175×75(Max)
-
Application:Robot, AGV, RGV
- Product number: 04EQ029-01
- Cell model：26650/3.2V/3.5Ah
- Battery specification: 26650/15S4P/48V/14Ah
- Nominal voltage：48V
- Nominal capacity：14Ah
- Charging voltage: 54.6V
- Charging current: ≤10A
- Discharging current: 40A
- Instant discharging current: 100A
- End-off voltage: 41.25V
- Internal resistance: ≤200mΩ
- Battery weight: 5.5kg
- Product dimension: 290×175×75(Max)
- Charging temperature：0～45℃
- Discharging temperature: -20～60 ℃
- Storage temperature: -20～40 ℃
- Temperature protection: 65℃±5℃
- Battery case: thermal shrinkage of PVC
- Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection, equilibrium, etc.
- Application field: robot, AGV, RGV
- 1. Copper nickel compositing with nickel strap: connect the batteries by copper nickel compositing with nickel strap, which is safe and reliable. It assures to work through large current.
- 2. Large current connector: apply Anderson large current connector, which has maximum current of 100A.
- 3. Communication interface: have RS485 communication protocol and can read the information of battery voltage, current, temperature, capacity, etc.
- 4. Data communication management: adopt software management chip, precise data transmission and accurate temperature control so as to try our best to eliminate the security risks.
- 5. Safety management of the battery: when the temperature probe of battery finds out over temperature status, the protection system is on automatically.
- 6. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
