Product number: 66AQ018-03
Cell model: JD6049B0/4100mAh/3.7V
Product size: 148mm*120mm*13mm
Nominal voltage: 11.1V
Nominal capacity: 8.2Ah
Charging voltage: 12.6V
Charging current: 4.1A
Discharge current: 4.1A
Discharge cut-off voltage: 7.5V
Product internal resistance: ≤200mΩ
Battery weight: 485G
Charging temperature: 0 ~ 45℃
Discharge temperature: -40 ~ 60 ℃
Storage temperature: -40 to +45 ° C (less than 1 month) -40 to 35 ° C (less than 3 months); -20~+25℃ (less than 12 months)
Battery packaging: PVC process
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, etc.
1.PVC process is simple, reliable and easy to install.
2.Output terminal: Adopt the output mode of GB UL wire to increase conductive reliability.
3.Battery protection management: Adopt imported well-known protection chips, featuring high stability, high precision monitoring and precise control, to eliminate safety risks to the maximum.
4.The battery pack is safe, has good discharge performance and long cycle life.
5.The battery pack has a long cycle life and conforms to the values of low-carbon, energy saving and environmental protection.
