Project number: 08DQ0047-01
Cell model: INR18650-35E/3350mAh/3.6V
Specification: 18650-4S2P/6700mAh/14.4V
Nominal voltage: 14.4V
Nominal capacity: 6700mAh
Charging voltage: 16.8V
Charging current: ≤ 3.4A
Discharge current: 10.0A
Instantaneous discharge current: 15.0A
Cut-off voltage: 10.5V
Internal resistance: ≤250mΩ
Battery weight: 550 GB
Product size: 22*68*151.5mm
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 ° C to 23 ° C
Battery case: /
Intelligent lithium battery protection: power management, short circuit protection, over charge protection, over discharge protection, over current protection, etc.
Application: Medical devices
