Project number: 33DZ10-01A
Cell model: 18650 3.6V/3350mAh
Battery specifications: 1S2P/3.6V/6.7Ah
Nominal voltage: 3.6V
Nominal capacity: 6.7Ah
Charging voltage: 4.2V
Charging current: ≤2A
Discharge current: ≤ 1.6A
Instantaneous discharge current: less than 3A
Discharge cut-off voltage: 3.0V
Internal resistance of finished product: ≤350mΩ
Battery weight: 100G
Product size: 21.5*38*68mm (Max)
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60 ℃
Storage temperature: -20 to 45 ° C
Battery case: PVC
Communication: no
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, over temperature protection, etc.
Application: Environmental monitoring equipment
Product Features
1.Exia T4;
2.Low energy consumption;
3.The battery pack is safe and has long cycle life.
4.The battery pack has a long cycle life and conforms to the values of low-carbon, energy saving and environmental protection.
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
