Project number: 08DQ0082-16
Cell model: 18650/2000mah /3.6V-LS
Specification: 18650-4S2P/4AH/14.4V
Nominal voltage: 14.4V
Nominal capacity: 4.0Ah
Charging voltage: 16.8V
Charging current: ≤4.0A
Discharge current: 10.0A
Instantaneous discharge current: 14.0A
Discharge cut-off voltage: 10.0V
Internal resistance: ≤250mΩ
Battery weight: 500G
Product size: 35*69*160.6mm
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 to 35°C
Battery case: ABS+PC
Intelligent lithium battery protection: power management, short circuit protection, over charge protection, over discharge protection, over current protection, etc.
Application: Defibrillator
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
