Custom Lithium ion Battery Pack
Product number: 35AQ1008-02
Cell model: 384683L/2200mAh/3.7V
Battery specification: 384683L-2S2P/ 4400MAH-7.4V
Nominal voltage: 7.4V
Nominal capacity: 4400mAh
Charging voltage: 8.4V
Charging current: ≤2200mA
Discharge current: 4.4A
Instantaneous discharge current: 6.0A
Discharge cut-off voltage: 5.0V
Internal resistance: ≤250mΩ
Battery weight: 200G
Product size: 5.15*91.3*190.3mm
Charging temperature: 0 ~ 45℃
Discharge temperature: -40 ~ 60℃
Storage temperature: 0 to 25 ° C
Battery case: /
Intelligent lithium battery protection: power management, short circuit protection, over charge protection, over discharge protection, over current protection, etc.
Application: Ruggedized laptop
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
