18650 10.8V12Ah Low Temperature Battery

Customization | Free Battery Solution

Product Detail

Product number: 36AQ0750-06

Cell model: 18650-3350 mah -3.6V

Battery specification: 18650-3S4P-12AH-10.8V

Product dimension: (L:163*W:53*H:66) ±1mm

Nominal voltage: 10.8V

Rated capacity: 12Ah

Charging voltage: 12.6V

Charging current: 6.4A

Discharge current: 8.0A

Discharge cut-off voltage: 7.5V

Finished internal resistance: ≤200mΩ

Battery weight: 810g

Charging temperature: 0 ~ 45℃

Discharge temperature: -43 ~ 55℃

Storage temperature: -20~+45℃ (less than 1 month) -20~ 35℃(less than 3 months); -20~+25℃ (less than 6 months)

Battery encapsulation: plastic case

Communication protocol: SMBUS

Output mode: GB UL wire

Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, over temperature protection, etc.

Application: Carrying radio batteries
