Custom Lithium ion Battery Pack
Project number : 37DZ001-01
Cell model: 18650/3.6V/3350mAh
Battery specification: 18650-3S4P/10.8V/16750mAh
Nominal voltage: 10.8V
Nominal capacity: 16750mAh
Charging voltage: 12.6V
Charging current: ≤8A
Discharge current: 8A
Instantaneous discharge current: 8-12A
Discharge cut-off voltage: 7.8V
Finished internal resistance: ≤150mΩ
Battery weight: 750g
Product dimension: 21*71*278mm
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 ~ 45 ° C
Battery encapsulation: PVC package
Lithium battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, SMBBUS, etc.
Application: rugged laptop
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
