Custom Lithium ion Battery Pack
Product number : 08DQ0028-02
Battery model: NCR18650GA6W / 3350 mah / 3.6 V
Battery Specification: 18650-4S6P/20.0Ah/14.4V (smart + stand)
Nominal voltage: 14.4V
Nominal capacity: 20.0Ah
Charging voltage: 16.8V
Charging current: ≤6.0A
Discharge current: 10.0A
Instantaneous discharge current: 15.0A
Discharge cut-off voltage: 11.2V
Finished internal resistance: ≤90mΩ
Battery weight: 1400g
Product dimension: 65.6*210mm
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 ~ 23 ° C
Battery case: ABS+PCS
Intelligent lithium battery protection: power management, short-circuit protection, overcharge protection, overdischarge protection, overcurrent protection, etc.
Application: Reconnaissance equipment
