Product number: 35AQ833-02
Cell model: 18650-2500mAh-3.6V
Battery specification: 18650-3S2P-5000mAh-10.8V
Product dimension: 200*43*20mm (Max)
Nominal voltage: 10.8V
Nominal capacity: 5000mAh
Finished internal resistance: ≤200mΩ
Charging voltage: 12.6V
Charging current: ≤2.5A
Discharge current: ≤5.0A
Discharge cut-off voltage: 7.5V
Battery weight: 300g
Charging temperature: 0 ~ 45℃
Discharge temperature: -40 ~ 60℃
Storage temperature: -20 ~ 35℃
Battery case: blue PVC heat shrinkable film
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over temperature protection, over current protection,ESD protection and so on
Application: laptop, reinforced laptop, portable computer
1.Blue PVC heat shrinkable film package is simple and reliable, and is easy to install;
2.The battery pack is assembled by special cell bracket, protected by epoxy plate and connected by special nickel sheet, which has good vibration and impact resistance.
3.Connector plug output terminal: Use the JST plug output method to increase the electrical conductivity of the plug.
4.Discharge lithium battery at a low temperature of -40℃;
5.Data communication management: Use TI-SMBus software to manage the chip, SMBus communication for precise data transmission, accurate temperature control, so as to maximize the elimination of security hazards.
6.The battery pack is safe, has good low-temperature discharge performance, high low-temperature rate, supports -40℃ rate discharge, and the discharge amount reaches more than 90%.
7.The battery pack has good safety, nice discharge performance,and long cycle life;
8.The battery pack has long cycle life, in line with the value of low carbon, energy saving and environmental protection;
