Product number: 05DQ0065-01
Cell model: 21700-4900mAh-3.6V
Battery specification: 21700-5S1P-4900mAh-18V
Product dimension: 108*76*23mm
Nominal voltage: 18V
Nominal capacity: 4900mAh
Internal resistance of finished product: ≤180mΩ
Charging voltage: 21V
Charging current: ≤2.5A
Discharge current: ≤3.5A
Discharge cut-off voltage: 12.5V
Battery weight: 400g
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 ~ 35 ° C
Battery package: Blue PVC heat shrinkable film
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over temperature protection, over current protection,ESD protection, etc.
Applications: Portable IVD equipment, portable medical equipment
Product Features:
1.Blue PVC heat shrinkable film package is simple, reliable and easy to install;
2.Connector plug output: Use MOLEX plug output to increase conductive reliability;
3.Battery protection and control: Adopt special lithium battery protection chip with good stability, high precision monitoring, precision control, temperature protection and other functions, so as to maximize the elimination of safety risks;
4.Data communications management: Use TI - SMBus software management chip, SMBus communication data transmission, accurate temperature control precision, so as to eliminate potential safety problems.
5.The battery has good safety, nice discharge performance and long cycle life.
6.The battery has long cycle life, which accord with low carbon, energy saving, environmental protection value concept.
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
