Product number: 35AQ528-06
Cell model: JD596869CL-4000mAh-3.8V
Battery specification: 7.6V to 4.0Ah
Product size: 75×70×14 (±0.2mm)
Nominal voltage: 7.6V
Nominal capacity: 4Ah
Charging voltage: 8.7V
Charging current: 4A
Discharge current: 4A
Discharge cut-off voltage: 5V
Internal resistance of finished product: ≤180mΩ
Battery weight: ≤280g
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 55℃
Storage temperature: -20~+45℃ (< 1 month) -20~ 35 ℃(< 3 months); -20~+25℃ (< 6 months)
Battery package: plastic case
Communication mode: I2C communication protocol
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, over temperature protection, etc.
Application: Laptop
