LF50 12.8V 50Ah Outdoor Monitoring and Ball Control Equipment Lithium Iron Phosphate Battery

Customization | Free Battery Solution

Product Detail

Product number: 01WQ0093-01

Cell model: LF50-50Ah-3.2V

Battery specifications: LF50-4S1P-50Ah-12.8V

Product size: 193*142*139mm

Nominal voltage: 12.8V

Nominal capacity: 50Ah

Internal resistance of finished product: ≤100mΩ

Charging voltage: 14.4V

Charging current: ≤30A

Discharge current: ≤30A

Discharge cut-off voltage: 11.2V

Battery weight: 6500g

Charging temperature: 0 ~ 45℃

Discharge temperature: -20 ~ 60℃

Storage temperature: -20 ~ 35 ° C

Battery package: blue PVC heat shrinkable film package

Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over temperature protection, over current protection,ESD protection, etc.

Application: outdoor monitoring and control equipment, outdoor standby power supply, outdoor equipment and other industrial equipment

Product Features

1.Blue PVC heat shrinkable film package is simple, reliable and easy to be installed;

2.The battery uses special epoxy board protection, special aluminum laser welding connection, o that is has good shock resistance and impact resistant performance;

3.Battery protection and control: Adopt special lithium battery protection chip with good stability, nice precision monitoring, accurate control and temperature protection function, so as to eliminate potential safety problems;

4.It has LED power indicator for real-time display of the current power;

5.It has low voltage switch control output, convenient real-time control battery;

6.The battery has good safety, nice discharge performance and long cycle life.

7.The battery has long cycle life, accord with low carbon, energy saving, environmental protection value concept;
