Product number: 40AQ036-01
Cell model: 18650-3350mAh-3.6V
Battery specification: 18650-3S2P-6700mAh-10.8V
Nominal voltage: 10.8V
Nominal capacity: 6700mAh
Charging voltage: 12.6V
Charging current: ≤3350mA
Discharge current: 1280mA
Maximum discharge current: 3350mA
Discharge cut-off voltage: 7.5V
Internal resistance of finished product: ≤180mΩ
Battery weight: 350g
Product size: 138*58*21mm (Max)
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ +55℃
Storage temperature: -20 ~ +35℃
Battery package: soft package
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over temperature protection, over current protection, ESD protection, etc.
Application: medical tablet, handheld device, portable device, security
