Product number: 35AQ905-02
Cell model: 18650-2500mAh-3.6V
Battery specification: 18650-4S3P-7500mAh-14.4V
Product size: 115*73*38mm
Nominal voltage: 14.4V
Nominal capacity: 7500mAh
Internal resistance of finished product: ≤200mΩ
Charging voltage: 16.8V
Charging current: ≤1.4A
Discharge current: ≤3.6A
Discharge cut-off voltage: 10.0V
Battery weight: 700g
Charging temperature: 0 ~ 45℃
Discharge temperature: -40 ~ 60℃
Storage temperature: -20 ~ 35 ° C
Battery package: Blue PVC heat shrinkable film
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over temperature protection, over current protection,ESD protection, etc
Application: special operation equipment, outdoor backup power supply, outdoor equipment and other industrial equipment
Product Features
1.Blue PVC heat shrinkable film package is simple, reliable and easy to install;
2.The battery uses special cell stent assembly, epoxy board protection, special nickel piece connection, which make nice shock impact resistant performance;
3.- 40 ℃ low temperature discharge lithium-ion batteries;
4.Battery protection and control: Adopt special lithium-ion battery protection chip with high stability, nice precision monitoring, precision control,good temperature protection function, so as to eliminate potential safety problems;
5.LED power indicator, real-time display of the current power;
6.Low voltage switch control output, convenient real-time control battery;
7.The battery has good safety, nice discharge performance at low temperature. Its low temperature ratio is high, and support -40 ℃ discharge.Discharge capacity reaches more than 90%;
8.The battery has good safety, nice discharge performance and long cycle life.
9.The battery has long cycle life, which accord with low carbon, energy saving, environmental protection value concept;
