Product number: 01DQ0030-10
Cell model: 21700-4900mAh-3.6V
Battery specification: 21700-2S1P-4900mAh-7.2V
Product size: 157*25*28mm
Nominal voltage: 7.2V
Nominal capacity: 4900mAh
Internal resistance of finished product: ≤150mΩ
Charging voltage: 8.4V
Charging current: ≤3A
Discharge current: ≤3A
Discharge cut-off voltage: 6.0V
Battery weight: 160g
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 ~ 35 ° C
Battery package: engineering plastic ABS+PC
Output mode: gold plated shrapnel
Lithium-ion protection: short circuit protection, over charge protection, over discharge protection, over current protection,ESD protection, etc.
Application: infrared thermal imaging equipment, portable infrared equipment
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
