Product number: 37DZ067-02C
Cell type: 26650/3.2V/3.3Ah
Battery specification: 5S3P/16V/9.9Ah
Nominal voltage: 16V
Nominal capacity: 9.9Ah
Charging voltage: 18.25V
Charging current: ≤5.0A
Discharge current: 10A
Instant discharge current: 30A
Discharge cut-off voltage: 11.5V
Finished internal resistance: ≤200mΩ
Battery weight: 3.0Kg
Product size: 88*120*210mm
Charging temperature: -20 ~ 45℃
Discharge temperature: -40 ~ 60℃
Storage temperature: -40 ~ 45℃
Temperature protection: 70℃±5℃
Battery case: aluminum sheet metal case
Lithium battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, temperature protection, balance and so on
Application: Backup power supply
1.High current output;
2.The battery comes with temperature protection,
3.The battery has NTC temperature output.
4.It has aluminum sheet metal housing and light weight.
5.The battery pack has good safety and long cycle life;
6.Fast charge 0.5C.
7.The battery pack has long cycle life, in line with low carbon, energy saving, environmental protection value concept.
