Product number: 04DQ0367-01
Cell model:982830/3.7V/1000mAh
Battery specification: 982830-1S1P/3.7V/1000mAh
Nominal voltage:3.7V
Nominal capacity:1000mAh
Charging voltage: 4.2V
Charging current: ≤1A
Discharging current: 1A
Instant discharging current: 1A
End-off voltage: 3.0V
Internal resistance: ≤180mΩ
Battery weight: 20g
Product dimension: 11*33*29.6mm(Max)
Charging temperature:0~45℃
Discharging temperature: -20~60℃
Storage temperature: -20~45 ℃
Temperature protection: /
Battery case: engineering plastic ABS+PC
Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, etc.
Application field: sports camera, motion DV
