Custom Lithium ion Battery Pack
Product number: 08DQ0002-03
Cell model: 32140/15Ah/3.2V
Battery specification: 32140-8S2P/30Ah/25.6V
Nominal voltage: 25.6V
Nominal capacity: 30Ah
Charging voltage: 29.2V
Charging current: ≤15A
Discharge current: 15A
Instant discharge current: 30A
Discharge cut-off voltage: 20.0V
Internal resistance of finished product: ≤350mΩ
Battery weight: ≤6kg
Product size: 180*210*210mm
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 ~ 25℃
Battery case: sheet metal case
Intelligent lithium-ion battery protection: power management (RS485,CAN protocol), short circuit protection, over charge protection, over discharge protection, over current protection, over temperature protection, etc.
Application: Radar broadband signal source equipment
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
