Product number: 04AQ826-03
Battery model: 18650-3350mAh-3.6V
Battery specification: 18650-3S2P-6700mAh-10.8V
Product size: 120*86*25mm (Max)
Nominal voltage: 10.8V
Nominal capacity: 6700mAh
Charging voltage: 12.6V
Charging current: ≤3.0A
Discharge current: ≤3.0A
Discharge cut-off voltage: 8.1V
Finished internal resistance: ≤200mΩ
Battery weight: 350g
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 ~ 35℃
Battery package: ABS+PC
Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overtemperature protection, overcurrent protection,ESD protection, etc.
Application: portable ultrasonic exploration equipment, portable flaw detection equipment
Product Features
1.ABS+PC shell increased battery reliability and firmness;
2.Connector plug terminal: Adopt knife clip connector output mode to increase conductive reliability;
3.Battery protection management: Use special lithium-ion battery protection chip with high stability, high precision monitoring, accurate control, temperature protection functions,so as to minimize security risks;
4.Data communication management: TI-SMBus software management chip, SMBus communication accurate data transmission, real-time battery status monitoring and control.
5.The battery pack has nice safety, good discharge performance and long cycle life;
6.The battery pack has long cycle life, in line with low carbon, energy saving, environmental protection value concept.
