Low Temperature 18650 3.6V 3350mAh Handheld Terminal Lithium-ion Battery

Customization | Free Battery Solution

Product Detail

Product number: 35AQ833-03

Battery model: 18650-3350mAh-3.6V

Battery specification: 18650-1S1P-3350mAh-3.6V

Product size: 69.5*φ19.5mm (Max)

Nominal voltage: 3.6V

Nominal capacity: 3350mAh

Finished internal resistance: ≤120mΩ

Charging voltage: 4.2V

Charging current: ≤1.5A

Discharge current: ≤3.0A

Discharge cut-off voltage: 2.5V

Battery weight: 50g

Charging temperature: 0 ~ 45℃

Discharge temperature: -40 ~ 55℃

Storage temperature: -20 ~ 35℃

Battery package: Blue PVC heat shrink film

Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection,ESD protection, etc.

Applications: Portable handheld devices, portable devices

Product Features

1.Blue PVC heat shrink film package is simple and reliable,and easy to install;

2.Use imported seiko protection chip and low internal resistance FETMOSF, with high stability, high precision monitoring, precise control, to minimize security risks.

3.Connector plug output terminal: using MOLEX plug output mode, increase the electrical reliability of the plug;

4.Low temperature -40℃ discharge lithium-ion battery;

5.The battery pack is safe and has good low-temperature discharge performance. It can discharge at -40℃ and discharge capacity can reach more than 60%.

6.The battery pack has nice safety, good discharge performance and long cycle life;

7.The battery pack has long cycle life, in line with low carbon, energy saving, environmental protection value concept.
