Product number: 05DQ0067-01
Battery model: 18650-3350mAh-3.6V
Battery specification: 18650-1S2P-6700mAh-3.6V
Product size: 68*38*21.5mm (Max)
Nominal voltage: 3.6V
Nominal capacity: 6700mAh
Finished internal resistance: ≤150mΩ
Charging voltage: 4.2V
Charging current: ≤2.0A
Discharge current: ≤2.0A
Discharge cut-off voltage: 2.5V
Battery weight: 110g
Charging temperature: 0 ~ 45℃
Discharge temperature: -40 ~ 60 ℃
Storage temperature: -20 ~ 35 ℃
Battery package: Blue PVC heat shrink film
Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection,ESD protection, etc.
Application: Temperature and humidity monitoring equipment, low temperature working equipment
Product Features
1.Blue PVC heat shrink film package is simple and reliable,and easy to install;
2.Connector plug output terminal: Use MOLEX plug output mode to increase the electrical reliability of the plug;
3.Use special lithium battery protection chip with high stability, high precision monitoring, accurate control and other functions,to maximize the elimination of security risks;
2.The battery has nice low-temperature discharge performance, supports -40℃ discharge, and its discharge capacity is more than 50%;
3.The battery pack has nice safety, good discharge performance and long cycle life;
4.The battery pack has long cycle life, in line with low carbon, energy saving, environmental protection value concept
