Product number: 01DQ0139-01
Battery model: 18650-2600mAh-3.65V
Battery specification: 18650-2S1P-2600mAh-7.3V
Product size: 68*38*22mm (Max)
Nominal voltage: 7.3V
Nominal capacity: 2600mAh
Internal resistance of finished product: ≤230mΩ
Charging voltage: 8.4V
Charging current: ≤1.3A
Discharge current: ≤1.3A
Discharge cut-off voltage: 5.6V
Battery weight: 100g
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 ~ 35℃
Battery package: Blue PVC heat shrink film
Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection,ESD protection, etc.
Application: infusion pump, portable medical equipment
Product Features
1.Blue PVC heat shrink film package is simple and reliable,and easy to install;
2.The battery pack is connected with a special battery cell and special nickel sheet, which has good shock resistance and impact resistance.
3.Connector plug output: Adopt JST plug output mode to increase conductive reliability;
4.Battery protection management: Use special lithium-ion battery protection chip, with high stability, high precision monitoring, accurate control,to minimize safety hazards;
5.The battery pack has nice safety, good discharge performance and long cycle life;
6.The battery pack has long cycle life, in line with low carbon, energy saving, environmental protection value concept
