Product number: 09AQ517-03
Cell model:18650/3.7V/2000mAh
Battery specification: 18650/4S1P/14.8V/2000mAh
Nominal voltage:14.8V
Nominal capacity:2000mAh
Charging voltage: 16.8V
Charging current: ≤1A
Discharging current: 1A
Instant discharging current: 2A
End-off voltage: 10V
Internal resistance: ≤250mΩ
Battery weight: 385g
Product dimension: 101×76×28(Max)
Charging temperature:0~45℃
Discharging temperature: -40~60 ℃
Storage temperature: -20~20 ℃
Battery case: Al6061 aluminum alloy
Lithium ion battery protection: short circuit protection, overcharging protection, over-discharging protection and overcurrent protection.
Application field: wireless test equipment
Product features
1. Shock-resistant and waterproof: fill in the shock-resistant structure inside the c aluminum alloy housing to satisfy the requirements of good security and high reliability.
2. Low temperature operation: adopt special low temperature battery and make sure that it works at -40℃.
3. Reliable connection: apply square connector, which is efficient, safe and reliable.
4. Capacity display: show the remaining capacity of the battery directly by 4 LED light.
5. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
