Product number: 01DQ0023-65
Battery model: 18650-3200mAh-3.6V
Battery specification: 18650-4S1P-3200mAh-14.4V
Product size: 71.5*38*38mm (Max)
Nominal voltage: 14.4V
Nominal capacity: 3200mAh
Finished product internal resistance: ≤260mΩ
Charging voltage: 16.8V
Charging current: ≤2.0A
Discharge current: ≤4.0A
Discharge cut-off voltage: 10.0V
Battery weight: 200g
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 ~ 35℃
Battery package: Blue PVC heat shrink film
Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overtemperature protection, overcurrent protection,ESD protection, etc.
Application: sweeping robot, robot
Product Features
1.Blue PVC heat shrink film package is simple and reliable, easy to install;
2.Connector plug output terminal: use MOLEX plug output mode to increase the electrical reliability of the plug;
3.Battery protection management: Use special lithium-ion battery protection chip, with high stability, high precision monitoring, accurate control, temperature protection and other functions,to eliminate safety hazards;
4.The battery pack has nice safety, good discharge performance and long cycle life;
5.The battery pack has long cycle life, in line with low carbon, energy saving, environmental protection value concept.
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
