Custom Lithium ion Battery Pack
Product number: 05DQ0068-04
Cell model: C40-20Ah-3.2V
Battery specification: C40-4S1P-20Ah-12.8V
Product size: 142*82*82mm
Nominal voltage: 12.8V
Nominal capacity: 20Ah
Finished internal resistance: ≤120mΩ
Charging voltage: 14.4V
Charging current: ≤5.0A
Discharge current: ≤5.0A
Discharge cut-off voltage: 8.8V
Battery weight: 1500g
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 ~ 35℃
Battery package: Blue PVC heat shrink film
Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overtemperature protection, overcurrent protection,ESD protection, etc.
Applications: power/national road and other intelligent video surveillance equipment, security equipment
Product Features
1.Blue PVC heat shrink film package is simple and reliable,and easy to install;
2.The battery pack is laser welded with special nickel sheet, which has good vibration resistance, shock resistance and connection performance.
3.Adopt MOLEX plug output mode to increase electrical conductivity reliability;
4.Use special lithium battery protection chip, with high stability, high precision monitoring, precise control, temperature protection and other functions, maximize the elimination of safety hazards;
5.The battery pack has nice safety, good discharge performance and long cycle life;
6.The battery pack has long cycle life, in line with low carbon, energy saving, environmental protection value concept.
