Custom Lithium ion Battery Pack
Product number: 13BQ1887-03
Cell model：18650/3.7V/2.2Ah
Battery specification: 18650-6S1P/22.2V/2.2Ah
Nominal voltage：22.2V
Nominal capacity：2.2Ah
Charging voltage: 25.2V
Charging current: ≤2A
Discharging current: 2A
Instant discharging current: 3.0A
End-off voltage: 18.0V
Internal resistance: ≤580mΩ
Battery weight: 400g
Product dimension: 136*58*30mm（Max）
Charging temperature：0～45℃
Discharging temperature: -20～60 ℃
Storage temperature: -20～35 ℃
Battery case: blue PVC
Lithium ion battery protection: short circuit protection, overcharging protection, over-discharging protection and overcurrent protection.
Application field: on-board computer terminal, rail traffic testing equipment
