Product number: 40AQ056-02
Battery model: 18650-3350mAh-3.6V
Battery specification: 18650-3S9P-30.15Ah-10.8V
Product size: 169*72*57mm (Max)
Nominal voltage: 10.8V
Nominal capacity: 30.15Ah
Finished internal resistance: ≤180mΩ
Charging voltage: 12.6V
Charging current: ≤10A
Discharge current: ≤12A
Discharge cut-off voltage: 7.5V
Battery weight: 1400g
Charging temperature: 0 ~ 45℃
Discharge temperature: -40 ~ 55℃
Storage temperature: 25±3℃
Battery package: Blue PVC heat shrink film
Output mode: JST plug
Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overtemperature protection, overcurrent protection,ESD protection, etc.
Application: emergency broadcasting equipment, multimedia equipment
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
