Product number: 08DQ0074-01
Battery model: C40-3.2V-20Ah
Battery specifications: C40-15S3P-48V-60Ah
Product size: (460×245×160) ±1mm
Nominal voltage: 48V
Nominal capacity: 60Ah
Charging voltage: 54.75V
Charging current: 30A
Discharge current: 40A
Discharge cut-off voltage: 30V
Finished internal resistance: ≤180mΩ
Battery weight: 25Kg
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 55℃
Storage temperature: -20~+45℃ (less than 1 month) -20~ 35℃(less than 3 months); -20~+25℃ (less than 6 months)
Battery package: black sheet metal case
Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, overtemperature protection, etc.
Application: Robots
Product Features
1.Sheet metal shell is simple and reliable, easy to install;
2.CAN communication protocol;
3.Adopt the national standard UL wire output mode to increase the electrical conductivity reliability;
4.Imported well-known brand protection chip, with high stability, high precision monitoring, precise control, to minimize the potential security risks;
5.The battery pack is safe, has good discharge performance and long cycle life;
6.The battery pack has long cycle life, in line with the value concept of low carbon, energy saving and environmental protection.
