Product number: 16AQ369-22
Battery model: INR21700-40T/4000mAh/3.6V
Battery specification: 21700-7S1P/3600mAh/25.2V
Nominal voltage: 25.2V
Nominal capacity: 3.6Ah
Charging voltage: 28.7V
Charging current: ≤2.5A
Discharge current: 15.0A
Instantaneous discharge current: 15.0A
Discharge cut-off voltage: 17.71V
Finished internal resistance: ≤200mΩ
Battery weight: 800g
Product size: 48*101.2*295mm
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 60℃
Storage temperature: -20 ~ 23℃
Battery case: ABS+PC
Intelligent lithium-ion battery protection: power management, short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, etc.
Field of application: Medical
