Custom Lithium ion Battery Pack
Color Doppler Smart Lithium-ion Battery 14.4V 6200mAh
IEC 60601-1:2012
Product number：09AQ109-06T
Specification：18650-4S2P/6200mAh/14.4V
Nominal voltage：14.4V
Nominal capacity：6200mAh
Executive standard：GB31241-2014
Charging temperature：0℃~+45℃
Discharging temperature：-20℃~+60℃
Internal Resistance：≤250mΩ
Product weight：410g
Product dimension：21.5×67×208mm
Battery management：SM Bus protocol, overcurrent/overvoltage protection, overcharge/overdischarge protection,Short circuit protection, internal balance, power monitor ETC
Product feature：BMS battery management,safe and reliable
Product certification：CE/CB(IEC62133)/UN38.3 ETC
We custom battery solutions for every application Please fill out the form below to request a quote. Our design team will be in touch within 24 hours to discuss your specifications.
