Product number: 37DZ013-01
Cell model:40120 2.4V/10Ah
Battery specification: 5S2P/12V/10Ah
Nominal voltage:12V
Nominal capacity:10Ah
Charging voltage: 14.25V
Charging current: ≤2A
Discharging current: 5A
Instant discharging current: 15A
End-off voltage: 7.5V
Internal resistance: ≤150mΩ
Battery weight: 1.4kg
Product dimension: 42×130×220mm(Max)
Charging temperature:0~45℃
Discharging temperature: -20~70 ℃
Storage temperature: -20~45 ℃
Battery case: PVC
Lithium-ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, etc.
Application field: battery of outdoor power monitoring communication
Product features
1. Support charge at -20℃.
2. Wide temperature discharge at -20~70℃.
3. The battery pack has good security and long cycle life.
4. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
